Dezibel Wall panels are available in several sizes and shapes, and can be combined endlessly to create the visual and acoustic effect you need. The panels also work well as message boards. They are an efficient way to reduce echoes and reverberation in public spaces. Moreover, they are a good complement to other sound absorption screens and solutions.

DIMENSIONS

Square
600 × 600, 700 × 700, 800 × 800, 1000 × 1000, 1200 × 1200 mm
(23.6”, 27.6”, 31.5”, 39.4”, 47.2”)

Rectangle
900 × 600, 1200 × 450, 1200 × 600
(35.4” x 23.6”, 47.2” x 17.7”, 47.2” x 23.6”)

1200 × 800, 1600 × 800, 1800 × 600, 1800 × 800 mm
(47.2” x 31.5”, 70.9” x 23.6”, 70.9” x 31.5”)
Available hanging vertically or horizontally.

Circle
ø600, ø800, ø1000, ø1200 mm
(ø23.6”, ø31.5”, ø39.4”, ø47.2”)

Thickness: 53 mm (2.1”), including distance from wall 72 mm (2.8”).
Dezibel wall is also available with a depth of 30 mm (1.2”)

DESIGN

Rear and frame of MDF. Stone wool filling and external cover of textile.
To be mounted using cable and cable lock.

Length of cable: 1500 mm (59.1”).

STANDARD FABRICS

Carlow Camira Fabrics Price group 1

Event Gabriel Price group 1

Sawana Davis Fabrics Price group 1

Blazer Lite Camira Fabrics Price group 2

Floyd Screen Kvadrat Price group 2

Blazer Camira Fabrics Price group 3

Remix Kvadrat Price group 3

Synergy Camira Fabrics Price group 3

Fiord Kvadrat Price group 4

Melange Nap Kvadrat Price group 4

For other fabrics, request quotation.
